RightMark Audio Analyzer test report
| Testing device | DAC - Philips chip removed |
| Sampling mode | 24-bit, 48 kHz |
| Interface | |
| Testing chain | External loopback (line-out - line-in) |
| RMAA Version | 6.2.1 |
| 20 Hz - 20 kHz filter | ON |
| Normalize amplitude | OFF |
| Level change | -7.1 dB / -7.2 dB |
| Mono mode | OFF |
| Calibration singal, Hz | 1000 |
| Polarity | inverted/inverted |
Summary
| Frequency response (from 40 Hz to 15 kHz), dB | +0.30, -0.88 |
Average |
| Noise level, dB (A) | -105.2 |
Excellent |
| Dynamic range, dB (A) | 105.4 |
Excellent |
| THD, % | 0.0014 |
Excellent |
| THD + Noise, dB (A) | -90.0 |
Good |
| IMD + Noise, % | 0.0039 |
Excellent |
| Stereo crosstalk, dB | -105.0 |
Excellent |
| IMD at 10 kHz, % | 0.0082 |
Very good |
| General performance | Very good |
Frequency response
| From 20 Hz to 20 kHz, dB | -0.88, +0.30 |
| From 40 Hz to 15 kHz, dB | -0.88, +0.30 |
Noise level
Left |
Right |
|
| RMS power, dB | -103.8 |
-103.4 |
| RMS power (A-weighted), dB | -105.5 |
-104.9 |
| Peak level, dB FS | -89.3 |
-88.4 |
| DC offset, % | -0.0 |
-0.0 |
Dynamic range
Left |
Right |
|
| Dynamic range, dB | +103.8 |
+103.7 |
| Dynamic range (A-weighted), dB | +105.5 |
+105.3 |
| DC offset, % | -0.00 |
-0.00 |
THD + Noise (at -3 dB FS)
Left |
Right |
|
| THD, % | +0.0015 |
+0.0013 |
| THD + Noise, % | +0.0034 |
+0.0033 |
| THD + Noise (A-weighted), % | +0.0032 |
+0.0031 |
Intermodulation distortion
Left |
Right |
|
| IMD + Noise, % | +0.0039 |
+0.0039 |
| IMD + Noise (A-weighted), % | +0.0034 |
+0.0033 |
Stereo crosstalk
Left |
Right |
|
| Crosstalk at 100 Hz, dB | -100 |
-106 |
| Crosstalk at 1000 Hz, dB | -102 |
-106 |
| Crosstalk at 10000 Hz, dB | -101 |
-102 |
IMD (swept tones)
Left |
Right |
|
| IMD + Noise at 5000 Hz, | 0.0063 |
0.0061 |
| IMD + Noise at 10000 Hz, | 0.0082 |
0.0081 |
| IMD + Noise at 15000 Hz, | 0.0103 |
0.0104 |
